| Category | Mobile and crawler cranes |
|---|---|
| Sub Category | Mobile cranes |
| Manufacturer | Liebherr |
| Model | LTM 1650-8.1/54/80 |
| Year Of Manufacturer | 2021 |
| Serial Number | on Request |
| Equipment Number | 22644 |
| Price | Price on Request (Price excl. VAT) |
Machine is sold by:
| Max. capacity (75 %) | 771,62 us ton |
|---|---|
| Internal Code Number | 22644 |
| Mileage | 17.972,54 mi |
|---|---|
| Working hours chassis | 820 |
| Hours/milage from | 13.6.2025 |
| Drive and steering | 16 x 8 x 16 / 1/2/3/4/5/6/7/8. |
| Size of wheels | 16.00 R 25 |
| Engine exhaust-stage | V |
| Working hours superstructure | 4591 |
|---|---|
| Working hours superstructure from | 2025-06-13 00:00:00 |
| Hookblocks / Crane hook (t) | 129,6 t (DH) / 37,5 t (DH) / 12,7 t |
| Counterweight (t) | 155 t / 20 t |
| Telescopic boom (m) / boom sections | 16,7 - 54 m / 4 // 17,4 - 80 m / 6 |
| Luffing fly jib / Lattice fly jib (m) | 21 - 91 m |
| Other features | Engine (make/type) / hp / kW: Liebherr D 9508 A7-05 / 686 / 505 Gearbox manufacturer / Type: ZF / SG / Traxon-Torque Type of axle suspension: yes Support basis L/B: 10,50 x 9,60 m Carrier cabin: yes Winch 1 cable pull / cable Ø: 126 kN / 25 mm Winch 2 cable pull / cable Ø: 126 kN / 25 mm Winch 3 cable pull / cable Ø: 140 kN / 25 mm Emergency operation of crane hydraulic: yes Crane driveable from: yes TÜV / SP-acceptance validity: 10.25 / 04.26 No. of winches: 3 UVV-acceptance validity: 10.25 Truck chassis type / Width: A82C / 3,00 m Eddy current brake: yes Sparewheel: 1 Fixed Fly jib / Adapter: 6 - 62 m / 0-38° hydr. 12 V-socket in both cabins: yes 8 counterweight slabs each with 5 t instead of 4 slabs with 10 t to get a better weight distribution for the transport: yes removable boom with luffing cylinder disassembly: yes working spotlight at boom head: yes Controlled from support: yes external starting connection for carrier: yes excenter with extension (VE) of the telescopic boom 4 m: yes high beam head light: yes radio remote control: yes Runner: H 49,6 t Camera system incl. colour display at the head of the telescopic boom and additional equipment: yes Aircondition: yes Aircondition: yes emergency shutdown button – carrier cabin and crane cabin: yes reversing light fixed on the rear-view mirror: yes bunk berth for carrier cabin: yes Guyed telescopic boom: yes Telescopic boom extension: 8 m (V2) supports for transportation of telescopic boom – contour pivot section: yes Safe load indicator: yes variable supporting base: yes immobilizer: yes additional support at the rear of the carrier: yes Additional heating: yes Additional heating: yes additional oil cooler: yes |
|---|
